Cabletron Systems 1800 Switch User Manual



Configuring SNA 9-19
Figure 9-6 LLC2 Originated Host Configuration Screen
[A],[A],[E],[D]
from Main Menu
Pressing
[M]
will display a screen similar to Figure 9-8.
Figure 9-7 LLC2 Terminated Host Configuration Screen
[A],[A],[E],[D]
from Main Menu
Pressing
[M]
will display a screen similar to Figure 9-8.
Node Name=nodexyz
SNA LLC2 Originated Session Configuration (Screen 1 of 2)
* Host Number: 1
A Host MAC Address 0C005A123402
B Session Type Originated
C T1 (100 msec) 10
D T2 (msec) 100
ETi 30
FN3 1
GTw 1
HN2 8
IPriority 0
J Bandwidth Allocation Group 1
K Routing Subscriber ID 1121000000*
L Source MAC Address Mask 40000470
M Connections - Screen 2
O pti on:
Node Name=nodexyz
SNA LLC2 Terminated Session Configuration (Screen 1 of 2)
* Host Number: 1
A Host MAC Address 0C005A123402
B Session Type Terminated
C T1 (100 msec) 10
D T2 (msec) 100
ETi 30
FN3 1
GTw 1
HN2 8
I Prior ity 0
J Bandwidth Allocation Group 1
K Routing Subs criber ID 1121000000*
L Con nections - Sc re en 2
Option:
