Configuring BSC Interactive 10-3
Figure 10-2 BSC Interactive Port Record, Screen 3
Del
(item H) lets you delete the remote subscriber that is currently
highlighted. You will be prompted:
Delete "n,"
where
"n"
is the
sequence number. Pressing
[Y]
will delete that line and move all entries
below it up one sequence number.
A BSC TPAD subscriber can specify only one remote device, which can be an HPAD
or an X.25 connection to the host. An HPAD subscriber can specify up to 16 remote
devices, any of which can be a TPAD or an X.25 connection to the host. Each con-
nection must be assigned a different local subscriber address.
You must also configure Device records for the attached BSC devices. See
"Configuring BSC Interactive Devices" on page 10-10.
Node Name=nodexyz
BSC Interactive Subscriber Information
* Port: 1 Link State: Linku p
* I/O: UN IVER SAL
AB C D E F G H
Sq Local Sub. Remote Sub. Atcl Rtytm Rty# ConnID Del
01 100101000000000 200201000000000N 60 0 10
02 100101000000001 211020100000000N 60 0 12
03 100101000000002 212202010000000N 60 0 13
04 100101000000003 203301000000000N 60 0 05
05 100101000000004 231020100000000N 60 0 08
Select
