21-6 SmartSwitch 1800 4.0 User Guide, Rev 01
●
Frames/sec (*10)
– number of frames transmitted/received per second over the
five-second reporting interval, multiplied by 10.
●
DiscF/sec (*10)
– number of outgoing/incoming discarded frames per second
over the five-second reporting interval, multiplied by 10.
Information in a Non-Frame Relay Display:
X.25 frame-level statistics are counts (per second, multiplied by 10) of these standard
LAPB commands and responses:
SABM
(set asynchronous balanced mode) (un-numbered command)
UA
(un-numbered acknowledgment) (un-numbered response)
DISC
(disconnect) (un-numbered command)
DM
(disconnect mode) (un-numbered response)
FRMR
(frame reject) (un-numbered response)
REJ
(reject) (supervisory command or response)
RR
(receive ready) (supervisory command or response)
RNR
(receive not ready) (supervisory command or response)
INFO
(information) (information transfer, command)
Frame Relay Utilization Statistics
Frame Relay Utilization statistics track traffic over a frame relay DLCI, and monitor
the usage by each configured group on that DLCI.
Press
[H]
at the Statistics Menu and, when prompted, enter:
●
Port
:
0–3
. (Default is
0
.)
●
DLCI
:
16–991
. (Default is
16
.)
●
Report Interval
(in seconds):
5–65535
. (Default is
5
.)
Figure 21-6 Frame Relay Utilization Statistics Display
[E],[H]
from Main Menu
Node Name=node_xyz
Frame Relay Utilization Statistics
RLP: 0 CIR In/Out (bit/sec): 512000 /512000
Port: 0 Bc In/Out (bit): 512000 /512000
DLCI: 16 Be In/Out (bit/sec): 0 /0
Date: 06/12/1997 Committed D ata In /Out: 5000 /4800
Time: 14:24:50 Exxcess D ata In /Out: 0 /0
Frames Rcvd 10000, Disc 0, Frames Xmit 1000
Conf / Act Actual Conf / Act Actual
BAG Percentage (bit/sec) BAG Percentage (bit/sec)
1 50/50 48000 2 25/25 25000
3 50/50 40000 3 25/25 23000
50/0 060/0 0
70/0 080/0 0
9 0/0 0 10 0/0 0
11 0/0 0 12 0/0 0
13 0/0 0 14 0/0 0
15 0/0 0 16 0/0 0
