Configuring BSC Batch 11-3
Figure 11-2 BSC Batch Port Record, Screen 3
BSC Batch Port Parameters
Table 11-1 BSC Batch Port Parameters
Parameter Valid Values Default Value
Port Type BSC-B
(not valid here)
Physical Port Interface
see explanation see explanation
Blocked Port Flag Y/N N
Line S peed 75 bps – 19.2 Kbps
1
9600 bps
Retransmission Period
(ms)
1–9999 2000
Maximum Retransmissions 1–99 5
Maximum Bytes per Frame 25–4105 4105
Generate Clock Y/N Y
Rcv Clock (TT) from DTE Y/N
2
N
EBCDIC Y/N Y
Transparent Text Supported Y/N Y
Ac k A–C
none
Controller Type A–F
none
Full Duplex Y/N Y
# of Beginning Sync Chars 2–10 2
# of Trailing Pad Chars 1–10 1
No Response Timer
(sec)
2–10 2
No Response Retry Count 4– 255 5
continued on next page
Node Name=nodexyz
BSC Batch Subscriber Information
* Port: 1
* I/O: V.35
A Sq B Local Sub. C Remote Sub. D Atcl E Rtytm F Rty# G Del
01 100101000000000 200201000000000N 60 0
02 100101000000001 211020100000000N 60 0
03 100101000000002 212202010000000N 60 0
04 100101000000003 203301000000000N 60 0
05 100101000000004 231020100000000N 60 0
