14-8 SmartSwitch 1800 4.0 User Guide, Rev 01
1
Y
for new interfaces,
N
for interfaces already configured when the current release of
SmartSwitch 1800 software is installed.
2
255.255.255.255
is valid only on a point-to-point interface.
3
The default value of
Network Mask
will be configured automatically, to reflect the
appropriate address class, after the
Source IP Address
is specified..
If the interface is
configured as unnumbered (and, therefore, no
Source IP Address
is configured), the
default value of
Network Mask
will be taken from the numbered interface that is
assigned.
If a
Source IP Address
is specified/changed, the
Network Mask
will automatically change to a default value appropriate
for the new address. For this reason, configure the
Source
IP Address
first, then the
Network Mask
.
4
These addresses must also be configured in Subscriber records (described on page 8-20),
and cannot contain wildcards. In the record for the Source Subscriber, do not configure
any Routing Path. In the record for the Destination Subscriber, configure
1st Routing
Path
as the node, RLP (only if FRX6000 or FRM), and X.25 port that will be used for
the physical interface. (On an FRX6000 or FRM, that RLP does not need to be the same
one that has IP installed.)
Table 14-3 X.25 IP Interface Parameters
Parameter Valid Values Default Value
Maximum Transmission Unit 1–4096 4096
Routing Metric Count 0–255 0
ICMP Redirects Y/N Y
RIP Support
0
(Enabled),
1
(Rcv only),
2
(Disabled)
0
(Enabled)
RIP Flash Updates
(sec)
5–300 10
RIP Full Updates
(sec)
10–300 30
Priority 0–9 5
Bandwidth Allocation Group 1–16 1
Interface Type X.25
n/a
Destination IP Address 1.0.0.0– 223.255.255.255
none
Unnumbered Interface Y/N
see note
1
Source IP Address 1. 0.0.0–223.255.255.255
none
Network Mask 25 5.0 .0 .0– 255.2 55.25 5.2 55
2
255.0.0.0
3
Source Subscriber
valid subscriber address
4
none
Destination Subscriber
valid subscriber address
4
none
SVC Retry Timer
(sec)
5–60 20
SVC Idle Timer
(min)
0–5 1
Max VCs to Establish 1–8 1
PVC Connection Y/N N
