Cabletron Systems 1800 Switch User Manual



Configuring BSC Batch 11-7
Subscriber Parameters
Sq
is a sequence number, which eases selection of a line on the screen to change. To move
to another line, press
[A]
and enter the sequence number.
Local Sub
is the calling address used by the local device. A Subscriber ID (see page 11-8) must
also be configured for this address.
Remote Sub
is the called address used for calls by the local device. A Subscriber ID (see page 11-
8) must also be configured for this address.
If the BSC port is one end of a connection to a logical X.25 port in the SmartSwitch,
this address must match a Subscriber ID configured for the logical port.
Atcl
(Autocall) causes a BSC device to automatically the remote end when it becomes
active.
Rtytm
is the Retry Timer, which is the time between autocall retries.
Rty #
is the Retry Number, which determines the maximum number of times an autocall will
be sent. Note that a value of
0
allows indefinite retries.
Del
lets you delete the remote subscriber that is currently highlighted. You will be
prompted:
Delete "n,"
where
"n"
is the sequence number. Pressing
[Y]
will delete that
line and move all entries below it up one sequence number.
