Status Displays 20-3
Disabled
– The link has been broken by the
Disable Port
operation (at the On-
Line Control menu).
Disconnect
– For X.25, level 1 is up but level 2 cannot be established. For
SNA HPAD, no XID or SNRM command frame has been received for any
link address configured for the HPAD subscriber.
Configured
– The port is configured in the database, but has been disabled.
Dial Ready
– The X.25 dial port is ready to transmit or receive calls.
Quiesced
– The port has been quiesced (described on page 19-12).
Failed
– Some modem controls are not present, and the physical link is down.
●
State
for Voice ports:
Configured
– The port is configured in the database, but has been disabled.
On Hook
– Self-explanatory.
Dialing
– Self-explanatory.
Wait on Accept
– The number has been dialed, but the device at the remote
end has not yet established a connection.
Call Active
– A call has been placed and answered
Pnd. on Hook
– The device at the remote end has been placed on hook while
the call was in progress.
Failed
– The physical link is down.
Displaying Virtual Connections
To display all physical and logical connections on a physical port, press
[C]
at the
Status Displays Menu and, when prompted, enter an
RLP port
number:
0–3
.
The display will differ depending on whether or not the port is a frame relay port.
Figure 20-3 shows a frame relay port and Figure 20-4 shows a non-frame relay port.
