20-4 SmartSwitch 1800 4.0 User Guide, Rev 01
Figure 20-3 Virtual Connections Display on Frame Relay Port
[C],[C]
from Main Menu
Information in this Display:
●
Seq
– is a sequence number used to identify the connection.
●
DLCI
– is the DLCI on which the connection exists.
●
State
:
Data_trans
– means that call processing was successful and the con-
nection is in the data transmission state.
Call_setup
– means that the attached device is waiting for Call Accept.
Clearing
– means that the attached device is in Call Clear state, waiting
for Clear Confirmation.
Resetting
– means that a Reset has been sent to the remote device, and the
attached device is waiting for a Reset Confirmation.
Port_down
– is self-explanatory.
Connected
– means that a connection has been established.
Not_conect
– means that a connection has not been established or has
been broken.
A frame relay DLCI displaying this state might have a backup that
is now in operation. To determine this, press
[F3]
to return to the
Status Displays
menu, then press
[F]
,
[E]
,
[B]
(
Display States for all
Primary DLCIs on a Port
), and enter the port number. If the DLCI is
displayed as
Backed Up
, note the backup DLCI, then press
[F3]
three times, then
[C]
at the Status Displays menu, and verify that
the backup DLCI is in
Data_trans
state.
●
Undefined
– means that the port is in some unknown state.
●
Trans
– is the number of transmitted frames.
●
Recd
– is the number of received frames.
●
Disc
– is the number of discarded frames.
Node Name=node_xyz
Connection Status Display Menu (Page 1) RLP: 0 Port: 0
From: Cumulative To:
SeqDLCI State Trans Recd Disc P DLCI State
1 16 D ata_trans 587 497 0 9 16 D ata_trans
2 17 Data_trans 588 574 0 10 17 Data_trans
3 18 Data_trans 592 586 1 11 18 Data_trans
4 20 Data_trans 580 486 0 14 20 Data_trans
5 32 Data_trans 585 602 6 18 28 Data_trans
6 33 Data_trans 600 594 0 19 29 Data_trans
7 34 Data_trans 621 600 0 22 30 Data_trans
8 35 Data_trans 579 543 0 23 31 Data_trans
9 36 Data_trans 586 584 0 24 32 Data_trans
10 25 Data_trans 588 586 4 30 25 Data_trans
11 24 Data_trans 593 610 0 29 24 Data_trans
12 42 Data_trans 602 498 5 33 42 Data_trans
13 43 Data_trans 610 506 0 34 43 Data_trans
14 44 Data_trans 585 560 0 35 44 Data_trans
