Statistics Displays 21-19
IPX Statistics Displays
IPX statistics track IPX traffic through a node. Press
[F]
at the Statistics Menu and,
when prompted, enter:
●
Interface Number
:
0–63
. (Default is
0
.)
●
Report Interval
:
5–65535
. (Default is
5
.)
Figure 21-14 IPX Statistics Display
[E],[F]
from Main Menu
There are three screens of IPX statistics. Pressing
[F7]
will display the next one (if
there is one), and pressing
[F6]
will display the previous one (if there is one). All IPX
statistics are listed below.
Information in this Display:
●
Pkts to Route
– is the number of IPX packets routed through the local node.
●
Hops Too Large
– is the number of routed packets that were discarded because
the hop count exceeded 15, the maximum allowable.
●
NetB Hops_2_Lrg
– is the number of NetBIOS packets that were discarded
because the hop count exceeded the number of NetBIOS Hops specified in the
IPX Interface record for the local FRX/FRM interface.
●
RIP No Net Addr
– is the number of RIP entries received with no network
address. The network address configured for the interface will be used.
●
Path Not Fnd Pkt
– is the number of RIP packets that cannot be transmitted
because a route to the destination network cannot be found.
●
RIP Pkts Tx
– is the number of RIP packets transmitted on the interface.
●
RIP G_Query Tx
– is the number of RIP General Queries transmitted on the
interface.
Node Name=node_xyz
IPX Statistics Dis play (Page 1 of 3)
Interface: 0 Report Interval (sec): 5
Current Time:–06/15/97 10:32:45
STATISTIC CURR CUMULATIVE STATISTIC CURR CUMULATIVE
Pkts to Route 10 10000 Hops Too Large 10 10000
NetB Hops_2_Lrg 10 10000 RIP No Net Addr 10 10000
Path Not Fnd Pkt 10 10000 RIP Pkts Tx 10 10000
RIP G_Query Tx 10 10000 RIP N_Query Tx 10 10000
RIP G_Resp_Tx 10 10000 RIP N_Resp Tx 10 10000
RIP Pkts Rcv 10 10000 RIP G_Query Rcv 10 10000
RIP N_Query Rcv 10 10000 RIP G_Resp Rcv 10 10000
RIP N_Resp Rcv 10 10000 RIP Aged_Entries 10 10000
RIP Prd_Broadcast 10 10000 RIP Upd_Broadcast 10 10000
RIP INV Net Rcv 10 10000 RIP Worse Rt Rcv 10 10000
RIP Ukn G_Query 10 10000 RIP Ukn N_Query 10 10000
RIP Ukn G_Resp 10 10000 RIP Ukn N_Resp 10 10000
PgUp, PgDn, F4:Clear Cumulative Statistics, Others:Exit
