Configuring Async Ports 12-9
Pressing
[J], [K], [M]
,
[N]
, or
[O]
will display more parameters, listed in Table 12-3.
Pressing
[L]
will display the async PAD profile parameters (listed earlier in this
chapter) that are resident in the SmartSwitch software.
Async PAD Port Parameters
Table 12-3 Async Port Parameters
Parameter Valid Values Default Value
Port Type
see explanation
X.25
Physical Port Interface
see explanation see explanation
Blocked Port Flag Y/N N
X.3 Line Speed
see explanation
1
none
Initial Profile Name
0–10 characters
90
Login Required Y/N Y
Parity 0–3 0
DCE Cable Attached Y/N N
Mask Link Alarms Y/ N N
X.25 Parameter Options
Generate M-bit Packets Y/N
3
N
Default Calling Address
valid Subscriber ID
4
none
Disable X.121 User Calls NN
Autocall Options
Au to cal l Y/N N
Autocall Delay
(sec)
0–255 0
Called Address
valid subscriber ID
5
none
Retry Count 0–10 (0
= retry indefinitely)
5
Retry Interval
(sec)
0–255 60
User Data
(ASCII) 0–12 characters none
Facilities
(hex) 0–28 characters none
Modem Signal Options
DTR/RTS Active When VC Up Y/N N
Input Signal Detection 0–5 1
(DSR)
RTS-CTS H/W Flow Control Y/N
1
N
Disconnect Options
Disconnect Timer
(min)
0–60 (0
= disable timer)
2
Disconnect Duration
(sec)
0–300 0
Timeout if No Login Y/N N
Timeout if No Call Y/N N
Timeout if No Data Y/N N
Disconnect if Clear Recvd Y/N N
Disconnect if Clear Sent Y/N N
continued on next page
