Configuring BSC Interactive 10-9
1 The software does not verify that a specified port exists. Make sure all specified ports are
configured in the database.
Subscriber Name
identifies the subscriber to the console operator.
Routing Algorithm
allows creation of a "hunt group" of ports (see example on page 8-22), for the purpose
of routing per a pre-selected algorithm:
0
= Round Robin – selects ports specified cyclicly in numerical order according
to the list of Redirection Addresses. If the selected port is unreachable or con-
gested, the Call Request will be sent to the next port. (If the port becomes
available again, it will be included in its assigned position.)
1
= Alternate Route on Line Failure – selects the first port that is not in a failed
state. If the selected port does not make a connection, the call will be cleared, even
if other ports are available.
2
= Alternate Route on Line Busy – selects the first port that has LCNs available
(is not busy). If the port has failed, the next available port will be selected.
3
= Least LCN with Throughput – selects the line with the minumum loading, cal-
culated by weight and number of LCNs in use on that line. (Each line is assigned
a weight proportional to its throughput within the routing path.)
If use of a routing algorithm is not desired, simply accept the default, and specify only
one routing path.
Systematic Redirection
will redirect (if
Y
) all calls to the alternate subscribers specified by the Redirection
Addresses. Consecutive attempts at call redirection will be made to each alternate sub-
scriber in the list, until the call is completed.
Redirect on Busy
will redirect calls (if
Y
) according to the Redirection Addresses if the primary sub-
scriber device is busy.
Redirect on Out of Order
Redirect on Busy Y/N N
Redirect on Out of Order Y/N N
Connection Priority 0–9 0
1st, 2nd,etc. Path Configured Y/N N
RL P
n/a
0
Port
Physical port:
0–3
1
Logical port:
8–63
1
0
Redirection Address 0,1,etc.
valid address none
Table 10-3 SVC Subscriber Parameters
Parameter Valid Values Default Value
