Cabletron Systems 1800 Switch User Manual



Status Displays 20-9
X.25 Line Monitor
The X.25 line monitor is used to monitor X.25, SDLC, BSC, and async ports. The fol-
lowing figure shows an example.
Figure 20-6 X.25 Line Monitor Display
[C],[E]
from Main Menu
Information in this Display
On each line:
The leftmost field shows the time, to hundredths of a second.
The next field displays
I
(Incoming) or
O
(Outgoing). (Outgoing packets are also
displayed in reverse video.)
The next field identifies the packet type.
D
,
M
, or
Q
appears between the packet type and the LCN field if the D, M, or Q
bit is turned on in the packet.
LCN
is the logical channel of a data session.
PR
is the packet receive sequence number.
PS
is the packet send sequence number.
LNG
is the length of the data in bytes.
The field to the right of the colon contains the data in a data packet. (Data
exceeding the screen width is displayed on the next line.)
09:23:05:16 I DATA LCN 4072 PR 4 PS 4 LNG 1024:56686520756190G801
09:23:05:27 I DATA LCN 4072 PR 4 PS 5 LNG 1024:46686521255190G811
09:23:05:27 I RR LCN 4071 PR 6 PS
09:23:06:05 O RR LCN 4072 PR 6 PS
09:23:06:18 O DATA LCN 4072 PR 6 PS 6 LNG 1024:557586707555090G85
09:23:07:13 O DATA LCN 4071 PR 6 PS 7 LNG 1024:54389450758090G859
