Bridge Filter Definition Parameters
Table 16-2 through Table 16-6 list the various filter parameters. Explanations of some
parameters follow the tables. Explanations of individual masks are not included below
because they were described in general under "How Filter Masks Work" on page 16-7.
Filter Name
helps the user identify the filter. The name is not used by the software.
Sq
is a sequence number to identify the entry.
Offset
is the number of octets into the frame to the octet that will be checked against the
Value and Mask.
Value
is used in conjunction with the Mask as described under "How Filter Masks Work" on
page 16-7.
Filter Name
helps the user identify the filter. The name is not used by the software.
Table 16-2 Bridge Generic Filter Parameters
Parameter Valid Values Default Value
Filter Name
1–31 characters none
Sq 1–16 1
Offset 0–254
(octets)
0
Value 0–ff
(hex)
0
Mask 0–ff
(hex)
0
Del
Allows you to delete the specific entry (defined by the sequence number)
Table 16-3 Bridge MAC Filter Parameters
Parameter Valid Values Default Value
Filter Name
1–31 characters none
Source MAC Address Value 0–ffffffffff
(6 bytes)
ffffffffff
Source MAC Address Mask 0–ffffffffff
(6 bytes)
ffffffffff
Destination MAC Address Value 0–ffffffffff
(6 bytes)
ffffffffff
Destination MAC Address Mask 0–ffffffffff
(6 bytes)
ffffffffff
