Configuring IPX 15-17
Figure 15-5 IPX RIP Route Record
[A],[D],[I]
from Main Menu
IPX RIP Static Route Parameters
1
The highest interface in the IPX Interface file.
Network
is the IPX network address of the network containing the node defined by
Node
Number
.
Hops
is the number of routers in a packet's path to the destination network.
Transport Time
is the time (in 55-millisecond units) that it will normally take a packet to reach the des-
tination network if this route is used.
Table 15-10 IPX RIP Static Route Parameters
Parameter Valid Values Default Value
Network 1–fffffffe
(4 bytes)
00000001
Hops 0–65535 1
Transport Time 0–65535 1
Router 0–fffffffffffe
(6 bytes)
000000000001
Interface 0–
note
1
0
Node Name=node_xyz
IPX Route Maintenance
* Type 0–RIP
* Route Number 23
A Network Address 0000f0ac
B Hops 26
C Transport Time 30
D Router 00000000ff34
E Interface 5
Option::
