21-22 SmartSwitch 1800 4.0 User Guide, Rev 01
●
Pkts Tx
– is the total number of RIP and SAP packets transmitted on the local
interface.
●
Tx Completions
– is the total number of successfully transmitted RIP and SAP
packets that originated at the local node.
●
Pkts Rcv
– is the total number of RIP and SAP packets received on the local
interface.
●
Tx Pkts Filtered
– is the number of packets denied transmission because of a
filter configured on the interface.
●
Rcv Pkts Filtered
– is the number of packets denied reception because of a filter
configured on the interface.
●
Pkts Forwarded
– is self-explanatory.
●
Echo Requests Rcv
– is the number of Echo Requests received on the interface.
●
Echo Replies Rcv
– is the number of replies to Echo Requests received on the
interface.
●
Err_Type Pkts Rcv
– is the number of Novell error packets received on the
interface.
●
Pkts Discarded
– is the number of packets discarded because the interface was
down.
●
Pkts_2_Large Rcv
– is the number of packets received that exceeded the
Maximum Transmission Units configured for the interface. These packets are
discarded.
●
Major/Minor Version
– are the version numbers of the IPX stack.
●
Rcv Header Error
– is the number of IPX packets received with incorrect header
information. The header should be 30 bytes and contain network, node, and
socket addresses for source and destination.
●
Ukn Sockets Rcv
– is the number of socket numbers received that could not be
identified. Some socket numbers (assigned by Novell) are:
0451
= NCP Process
0452
= SAP Process
0453
= RIP Process
0455
= NetBIOS Process
0456
= Diagnostics Process
●
Rcv BSys Discard
through
R_Decomp Errors
– are not monitored by the FRX/
FRM, but are included in the statistics list because it is part of the IPX MIB. The
statistics in the list between the above two are:
Bad Checksum Rcv, Local Rcv
Pkts, Path_Not Found, Local Tx Pkts, Bad Local Tx Pkts, Tx BSys Discard, Open
Socket Fail, State Changes, Init Fail, Ms to Tx 1 Byte
●
R-RIP Ent-Filter
– is the number of received RIP entries discarded due to a filter.
●
T-RIP Ent-Filter
– is the number of transmitted RIP entries discarded due to a
filter.
●
R-SAP Ent Filter
– is the number of received SAP entries discarded due to a filter.
●
T-SAP Ent-Filter
– is the number of transmitted SAP entries discarded due to a
filter.
●
R-RIP Pkt-Filter
– is the number of received RIP packets discarded due to a RIP
router filter.
●
T-RIP Pkt-Filter
– is the number of transmitted RIP packets discarded due to a
RIP router filter.
