15-10 SmartSwitch 1800 4.0 User Guide, Rev 01
IPX Interface Parameters
Table 15-7 through Table 15-9 list parameters specific to frame relay, X.25, and LAN
interfaces, respectively. Explanations of most parameters follow Table 15-9.
Frame Relay Interface Parameters
1
Default value is
Ethernet
or
802.5
(depending on hardware) for Interface
0
, and
FRL
for
Interface
1–63
.
2
If set to greater than
0
(see note 4),
RIP Age Timer
must be 3 times longer than
Periodic
RIP Timer
, and
SAP Age Timer
must be 3 times longer than
Periodic SAP Timer
.
3
A value of
0
disables aging.
4
Valid port numbers depend on the model of SmartSwitch 1800—see port locations on
page 6-1. Make sure the port is not configured (in the Port record) for backup use only.
(See page 7-18.)
5
Make sure the DLCI is not part of a frame relay DLCI backup group or intra-nodal
frame relay PVC (both described in Chapter 7).
Table 15-7 IPX Frame Relay Interface Parameters
Parameter Valid Values Default Value
Blocked Port Flag Y/N N
Interface Type
FRL
Depends on inter-
face number
1
Frame Type TYPE_II TYPE_II
Maximum Transmission Unit
(frame size)
31–4096
(bytes)
4096
IPX Network Address 1–fffffffe 000 00000
Priority 0–9 5
Bandwidth Allocation Group 1–16 1
Port Diagnostics Enabled Y/N N
NetBIOS Enabled Y/N N
NetBIOS Hops 0–255 8
Periodic RIP Enabled Y/N N
Periodic RIP Timer
(seconds)
1–65535
2
60
Periodic SAP Enabled Y/N N
Periodic SAP Timer
(seconds)
1–65535
2
60
RIP Enabled Y/N N
RIP Age Timer
(seconds)
0–65535
2,3
180
RIP Maximum Size
(bytes)
54–446 446
SAP Enabled Y/N N
SAP Age Timer
(seconds)
0–6 55 35
2,3
180
Transport Time
(55ms ticks)
1–255 1
Serialization Enabled Y/N N
Watchdog Spoofing Enabled Y/N N
IPXWAN Enabled Y/N N
Source Card 00
Source Port 0–7
4
0
Source DLCI 16–991
5
16
