11-8 SmartSwitch 1800 4.0 User Guide, Rev 01
Configuring Subscriber Addresses
This operation configures the called and calling addresses that will be used in call
setup. To complete the connection, the software must recognize where the call is
coming from (calling address) and where it is going (called address).
To display a list of current Subscriber IDs (addresses), press
[A]
at the Connections and
Routing Paths Menu
(or
[A], [D], [A]
from the Main Menu).
To add or change a Subscriber ID, press
[B]
at the Connections and Routing Paths
Menu. When prompted, enter a Subscriber ID of up to 15 digits. (ID conventions are
described on page 8-21.
)
Figure 11-3 Typical SVC Subscriber Screen
[A],[D],[B]
from Main Menu
Pressing
[G]
will display routing paths, which link the subscriber with one or more
ports. Pressing
[H]
will display the addresses used for call redirection. (These
addresses are valid only if
Y
is specified for one or more of items C, D, and E on the
first screen.) Parameters for all three screens are described following Table 11-2.
Node Name=nodexyz
SVC Subscriber Maintenance
* Subscriber ID 0100012345
A Subscribe r N ame su b1
B Routing Algorithm 0, Round Robin
C Systematic Redirection N
D Redirect on Busy N
E Redirect on Out of Order N
F Connection Priority 0
G Routing Paths
H Redirection Addresses
Option:
