Router
Is the hex value of the node address of the router that will forward a packet when this
route is used. If Novell's IPXWAN protocol is used on the interface (as configured in
the IPX Interface file, described earlier in this chapter), this field will be ignored.
Interface
is the IPX network number assigned to the interface used to send packets that are using
this route.
IPX SAP Static Route Parameters
Service Type
is a SAP Service Type code. Some common types are:
0003
= print queue
0004
= file server
0005
= job server
0007
= print server
0009
= archive server
0024
= remote bridge server
Server Name
identifies a specific server in the IPX internetwork.
Server Network Address
is an IPX network number assigned to the network containing the server identified by
Server Name.
Server Node Address
identifies the IPX node attached to the server network.
Server Socket Number
is an IPX socket number that identifies the process. For example, the SAP process is
0452
.
Intervening Networks
is the number of routers that a packet must pass through to reach the server, if this
route is used.
Table 15-11 IPX SAP Static Route Parameters
Parameter Valid Values Default Value
Service Type 0–65535 0
Server Name
1-48 characters asterisk (wildcard)
Server Network Address 1–fffffffe
(4 bytes)
00000001
Server Node Address 1–fffffffffffe
(6 bytes)
000000000001
Server Socket Number 0–ffff 0000
Intervening Networks 1–65535 1
Router 1–fffffffffffe
(6 bytes)
000000000001
Interface 0–65535 0
