Configuring Voice 13-5
Speed Map Dial Digits
specifies the number of digits that are used for speed-dial and
auto-dial
numbers. (A
speed-dial number is a short substitute for a longer number, and an auto-dial number
will be dialed automatically when the receiver is taken off-hook.)
Voice Rates Minimum
specifies the minimum operating rate of all voice channels when congestion occurs.
Voice Rates Maximum
specifies the maximum operating digitization rate of all voice channels.
User Dialed Extended Dial Digits
specifies the number of extended dial digits that must be entered by the user of
attached equipment as part of a dial string when Source of Extended Digits in a port’s
Voice Port record is set to
User
.
Speed-dial numbers and extended digits can be output by remote voice/fax ports.
Extended digits will be forwarded to the remote end of the frame relay connection if
all of these conditions are met:
Extended dial digits are configured in the speed-dial map.
The parameter
Forwarded Output Digits
in the Voice Port record is set to
All
to
Ext
.
The parameter
Source of Extended Digits
in the Voice Port record is set to
Map
.
If the first two conditions are met, but
Source of Extended Digits
is set to
User
, the
operator must enter the extended dial digits to be forwarded.
Setting the number of extended digits to a value greater than zero reduces the number
of allowable entries in the speed-dial map table. When
Extended Dial Digits
is
0
, up to
512 map table entries can be defined. When
Extended Dial Digits
is greater than
0
, only
256 entries can be defined.
See the Store and Forward Dialing examples on page C-1 for more information about
how this parameter is used.
Guam 671 Norway 47 Vatican City 39
Guantanamo Bay 53 Pakistan 92 Venezuela 58
Guatemala 502 Panama 507 Wales 44
Guyana 592 Paraguay 595 Yugoslavia 38
Haiti 509 Peru 51 Zaire, Rep. 243
Honduras 504 Philippines 63 Zambia 260
Hong Kong 852 Poland 48 Zimbabwe 263
India 91
Table 13-2 International Dialing Country Codes
Country Code Country Code Country Code
(continued)
