Cabletron Systems 1800 Switch User Manual



Configuring SNA 9-21
LLC2 Host Parameters
1
Except
ffffffffffff
. Must be in 802.5 (Token Ring) format, which may require "bit
swapping" when entering the address. (See the explanation of
Host MAC Address
.)
2
A host address can be configured for one Originated and one Terminated session, but no
more than one each.
3
Must be less than the value for
T1
to ensure that the remote link station will receive the
delayed acknowledgment before
T1
expires.
4
An asterisk wildcard can be used as a final digit. (The
?
wildcard is not valid.) If fewer
than 15 digits are entered, an asterisk must be the final character.
5
1st digit must be
4, 5, 6
, or
7
, and an asterisk wildcard can be used as a final digit. If fewer
than 8 actual digits (not including an asterisk) are specified, zeros will be added to total
8 actual digits. This value must not conflict with the Locally Administered MAC
Address, described on page 6-5.
6
Displayed only if
Session Type
is
Terminated
.
7
Although selecting this item toggles between SNA and LLC2,
Type
must be
LLC2
.
8
Each
Local Subscriber ID
must begin with all of the actual Routing Subscriber ID. A
Local
or
Remote Subscriber ID
can contain an asterisk as the final digit; if so, the
asterisk will not be a "universal" wildcard, but instead will include the range
000–511
,
or
00–99
if 13 digits precede the wildcard, or
0–9
if 14 digits precede the wildcard.
9
Maxdata
will be overridden by
Maxdata
in the SNA PU parameters, and
Ma xin
will be
overridden by
Tw
in the LLC2 parameters.
Table 9-4 LLC2 Host Parameters
Parameter Valid Values Default Value
Host MAC Address
valid MAC address
1
400000000001
Session Type Originated/Terminated
2
Terminated
T1
(100 msec)
1–250 10
T2
(msec)
100–5000 3 100
Ti
(sec)
1–50 30
N3 1–127 3
Tw 1–127 7
N2 0–255 8
Priority 0–9 0
Bandwidth Allocation Group 1–16 1
Routing Subscriber ID
up to 15 digits
4
none
Source MAC Address Mask
up to 8 hex digits
5
40000000
On-Line Temporary Changes Y/N Y
Connections Parameters
Sq 1–16 1
HS AP 04–fe
hex, in multiples of 4
04
Type
6
LLC2
7
LLC2
Local Subscriber ID
up to 15 digits
8
none
Remote Subscriber ID
up to 15 digits
8
none
IDBLK 000–fff 000
IDNUM 00000–fffff 00000
Maxdata
265, 521, 1033, 1289, 1545,
2057
9
65
MaxIn 1–127
9
1
