Statistics Displays 21-5
Frame-level Statistics
Frame-level statistics are frame relay (if the port is configured for frame relay) or X.25
level 2 statistics (per second, multiplied by 10).
Figure 21-5 Frame-level Statistics Display
[E],[B],[F]
from Main Menu
This example shows an X.25 frame-level display. A frame relay display
will not include the two lines below
Start Time
.
The information on those two lines includes the current and previous level
2 states, and the time in the current state.
Information in a Frame Relay Display:
●
DE/sec (*10)
– number of frames transmitted/received with the DE (Discard
Elgibility) bit set per second over the five-second reporting interval, multiplied
by 10.
●
FECN/sec (*10)
– number of frames transmitted/received with the FECN
(Forward Event Congestion Notification) bit set per second over the five-second
reporting interval, multiplied by 10.
●
BECN/sec (*10)
– number of frames transmitted/received with the BECN
(Backward Event Congestion Notification) bit set per second over the five-
second reporting interval, multiplied by 10.
●
LMI/sec (*10)
– number of frames transmitted/received using LMI frame man-
agement per second over the five-second reporting interval, multiplied by 10.
●
ANXD/sec (*10)
– number of frames transmitted/received using Annex D frame
management per second over the five-second reporting interval, multiplied by
10.
Node Name=node_xyz
Frame Statistics Display
RLP : 0
Port: 1
Report Interval (sec): 5
Start Time: 4/21/1997 09:41:49
L2 State: Current Previou s Total Time in Current State
Information Transfer SABM Outstanding 0 Days 1 Hrs 4 Mins
Transmitted Received
CD FRAM E TY PE CUR R MA X C URR MA X
A SABM/sec (*10) 100 100 0 0
B UA/sec (*10) 0 0 100 100
C DISC/sec (*10) 0 0 0 0
D DM/sec (*10) 0 0 0 0
E FRMR/sec (*10) 0 0 0 0
F REJ/sec (*10) 0 0 0 0
G RR/sec (*10) 50 50 25 25
H RNR/sec (*10) 0 0 0 0
I INFO/sec (*10) 500 500 500 500
F2:Next F4:Clear Max F9: Stop Remote F10: Reboot Remote Others:Exit
