Filtering/QoS Information
GR2K-GA-0014 1-71
Ver. 07-02
Specifies the maximum contract band restriction by kbit/s. Specifies burst size
in byte unit. If a value greater than the line speed is set, no action at breach is
taken.
When setting this parameter, it is not possible to set -upc, or -upc_burst.
Packets exceeding the maximum band when setting this parameter are all
discarded.
When this is used, the number of entries used per list may become two or four
entries.
(This parameter is effective only for RP-C, RP-D, RP-C6, RP-D6, RP-CV, RP-DV,
GR2000-1B and GR2000-2B.)
Default: None. (No contract band surveillance is executed.)
Range of value: <kbps>: 0 to 2400000 (0 to 2.4G) (10-decimals).
If0to11isspecifiedinthecaseofRP-A,theoperationis
performed by taking the contract band as 12[kbps].
If 0 to 4 is specified in the case of RP-C, RP-D, RP-C6, RP-D6,
RP-CV, RP-DV, GR2000-1B, GR2000-2B, GR2000-2B+ and
GR2000-BH, the operation is performed by taking the contract
band as 4.1[kbit/s].
<Byte>: 0 to 131072 (10-decimals)
Specifies the minimum band assurance by kbit/s. Specifies burst size in byte
unit. If a value greater than the line speed is set, no action at breach is taken.
When setting this parameter, it is not possible to set -upc, or -upc_burst.
When this parameter is used, the number of entries used per list may become
two or four entries. (*1)
(This parameter is effective only for RP-C and RP-D.)
Default: None. (No contract band surveillance is executed.)
Range of value: <kbps>: 0 to 2400000 (0 to 2.4G) (10-decimals).
If0to11isspecifiedinthecaseofRP-A,theoperationis
performed by taking the contract band as 12[kbit/s].
If 0 to 4 is specified in the case of RP-C, RP-D, RP-C6, RP-D6,
RP-CV, RP-DV, GR2000-1B, GR2000-2B, GR2000-2B+ and
GR2000-BH, the operation is performed by taking the contract
band as 4.1[kbit/s].
<Byte>: 0 to 131072 (10-decimals)
Specifies the connection branching index number (index specified in the DLCI
group information or the Ve-Group information). It selects and transmits DLCI/
VC specified in the group when relaying the packet that agrees with the flow
detecting conditions. For the list information setting the connection branching
index number, specify out (Outbound) as the flow control of the output side.
(This parameter is effective only for RP-C, RP-D, RP-C6, RP-D6, RP-CV, RP-DV,
GR2000-1B, GR2000-2B and GR2000-2B+.)
Default: None.
