Operation Management Information
GR2K-GA-0014 4-23
Ver. 07-02
Description: Specifies the net mask address
Default: No mask
Range of Value: Net mask address in dot notation
Description: These parameters, if specified, execute actions below.
Ignores all accesses from the specified host.
Ignores all the NTP Mode 6 and Mode 7 packets sent from the
specified source. Time service with that source continues.
Allows only referential access from the specified host, using
theNTPMode6andMode7packets.
Ignores packets from the specified host other than those of
Mode 6 and Mode 7. As a result, no time service is given to
that host.
Treats the specified host not as a peer.
Treats the specified host not as a server for time data
synchronization.
Accepts only the first-issued time data request from a client
belonging to the specified net. Any other time data request
issued later from the other clients of the specified net is
rejected in accordance with the clientlimit parameter
setting.
Accepts only the packets issued from the NTP port.
Default: When none of the above parameters are specified, “-ignore
-ntpport” is assumed by default.
Description: Specifies the maximum number of clients that can access the
same NTP server at a time per network
.
Default: 3
Range of Value: (<key>): 1–4294967295 in decimal
Description: Specifies the local time server definition and the stratum
setting
. This definition applies when no remote time
server exists in the network to which the router
ordinarily connects.
Default: On with the stratum setting of 8.
Range of Value: (<int>): 1–255 in decimal.
Description: Specifies the delay time in seconds with which a broadcast or
multicast packet arrives
.
Default: 0.004 when no value is specified
Range of Value: Less than 1 in fixed-point decimal
