Hitachi Gigabit Router GR2000 Series Enhanced Version Configuration Commands, Vol. 2
5-36 GR2K-GA-0014
Ver. 07-02
import: invalid number of route-filter lists value
at <Value> not in range 1 to 8
Specified route filter count is over the limit. Specify the count up to 8.
<Value>: Specified route filter count
import: invalid octet value at <Value> not in
range 0 to 255
More than 255 values are defined in dot notation. Specify value
within the range of 0 to 255.
<Value>: Specified value
import: invalid preference value at <Value>
not in range 2 to 255
Preference value is invalid. Specify a value within the range of 2 to
255.
<Value>: Specified preference value
import: invalid policy group number value at
<Group Number> not in range 1 to 16
Policy group number value is out of valid range. Specify value within
the range of 1 to 16.
<Group Number>: Specified policy group number
import: invalid range end: <Value> In aspath_term{m,n}, m>n or n is more than 256. Set a start value
less than the end value or assign a value less than 255 to the end
value.
<Value>: Specified end value (n)
import: invalid range start: <Value> In aspath_term {m, n}, {m}, {m,}, more than 256 is specified for m.
Use a value less than 255.
<Value>: Specified start value (m)
import: invalid route-filter number value at
<Value> not in range 1 to 65535
ID number is out of valid range. Specify value within the range of 1 to
65535.
<Value>: Specified ID number
import invalid vpn number value at <Value>
not in range 1 to <Max_Value>
VPN number is out of valid range. Specify a value within the range of
1 to <Max_Value>.
<Value>: Specified VPN number
<Max_Value>Maximum VPN number
import: IPv6 Interface not found at ’<Interface
name>’
The interface of the specified interface name cannot be found.
Specify it by using the defined interface name.
<Interface name>: Specified interface name
import: IPv6 prefix cannot be linklocal in
configuration
The link local address is specified in the network address. Do not use
the link local address.
import: IPv6 prefix cannot be multicast in
configuration
The multicast address is specified in the network address. Do not
use the multicast address.
import: linklocal address should be followed
by %(IPv6 interface name)
An interface name is not specified in the specified link local address.
Specify an interface name with the percent (%) interposed when
specifying a link local address.
import: low end of range (<Value1> bits) is
greater than high end (<Value2> bits)
In the between specification, lower limit of the mask range is greater
than upper limit.Reduce lower limit value of the mask range to less
than upper limit value.
<Value1>: Lower limit of mask range
<Value2>: Upper limit of mask range
import: low end of range <Mask1> shorter
than prefix mask <Mask2>
In the between specification, lower limit of the mask range is
overlapped with specified mask. Correct the value so the mask range
does not overlap with specified mask.
<Mask1>: Lower limit of specified risk range
<Mask2>: Specified mask
import: mask not contiguous Bit 1 of the specified mask does not continue. Use a mask where bit
1 continues.
import: metric option of route-filter must not be
define for {import filter | bgp | bgp4+}
The metric option for the route filter is defined in the import filter or
the BGP/BGP4+ protocol. Do not specify the metric option.
import: Non-masked bits not zero for
<Address> mask <Mask>
At mask, 1 is set to non-masked bit of the specified address. Set
non-masked bit 0.
<Address>: Specified address
<Mask>: Specified mask
Table 5-5 Routing Protocol Error Messages (continued)
