Encore Presentation System • User’s Guide • Rev 04 109
4. Controller Orientation
Controller LC Front Panel
3) Alphanumeric Keypad
The Alphanumeric Keypad is reserved for numeric functions. This section is
only available on the LC Controller. Refer to the “
Alphanumeric Keypad” section
on page 119 for additional details.
4) Joystick Section
The Joystick Section includes a 3-axis joystick that enables you to adjust PIPs,
Keys and additional system parameters. The section also includes dedicated
buttons that change the Joystick’s function. Refer to the “
Joystick Section
heading on page 120 for details.
5) Machine Control Section
The Machine Control Section is reserved for controlling external devices. This
functionality is only available on the Controller LC. Refer to the “
Machine Control
Section” heading on page 122 for details.
6) Console Lighting
The Console Lighting Section enables you to control the three low-voltage
“script” lights. Refer to the “
Console Lighting” section on page 122 for details.
7) Preset Section
The Preset Section enables you to store and recall Controller setups, called
“presets.” Each button represents a single “look” of the overall projected image.
On the Controller LC, you have access to 900 presets — 30 pages of 30 presets
each. Refer to the “
Preset Section” heading on page 123 for details.
8) Destination Bus
The Destination Bus enables you to route the Controller’s output to one or more
destinations, such as projectors, ScreenPRO-IIs and auxiliary monitors. On the
Controller LC, 32 destinations are available. Refer to the “
Destination Bus
section on page 125 for details.
9) Source Selection Bus
The Source Selection Bus allows you to choose the sources that are routed into
PIPs and Keys. On the Controller LC, up to 64 sources can be mapped to
buttons. Refer to the “
Source Selection Bus” section on page 126 for details.
10) Layer Control Section
The Layer Control Section enables you to assign sources to PIPs and Keys on
each layer. Here, you control the overall look on Preview, prior to transitioning the
setup to Program. On the LC, up to 12 layers on six mixers can be controlled.
Refer to the “
Layer Control Section” heading on page 128 for details.
11) Layer Functions Section
When a layer is active (and blinking) in the Layer Control Section, all buttons in
the
Layer Function Section now apply to that selected layer, enabling you to
change its mode and manipulate the source. Refer to the “
Layer Functions
Section” heading on page 131 for details.
12) Live Switch Section
The two buttons in the Live Switch Section temporarily change the function of
the
Source Selection Bus, enabling you to take sources “live” to Program. Refer
to the “
Live Switch Section” heading on page 134 for details.
