5. Menu Orientation
System Menu
~ D/As must be set up like routers. This enables you to define which D/A
outputs are patched to which specific Video Processor connectors.
• Number of Inputs — identifies the number of inputs on the selected router.
• Number of Outputs — identifies the number of outputs on the selected router.
• Communication Type — sets the router’s communication type, either RS-232,
ETHERNET or LANTRONIX.
• Press {COMM SETUP} to display one of three Comm Setup Menus, depending
on the selected
Communication Type. Refer to the “Comm Setup Menus”
section on page 191 for details.
• Press {DELETE ROUTER} to change the selected router Number to undefined.
• Press {ADD NEW} after choosing an “EMPTY” router number to begin the
definition process — in order to create a valid router specification.
• Press {OUTPUT PATCH} to display the Output Patch Menu. Refer to the
“
Output Patch Menu” section on page 194 for details.
`çãã=pÉíìé=jÉåìë
Information is provided for three different Comm Setup Menus:
• Ethernet Setup Menu
• RS-232 Setup Menu
• Lantronix Setup Menu
Ethernet Setup Menu
On the Router Specification Menu, when Communication Type is set to ETHERNET,
press
{COMM SETUP} to display the Ethernet Setup Menu:
Figure 5-37. Ethernet Setup Menu (sample)
The Ethernet Setup Menu enables you to set the router’s IP address and port number.
• IP Address — sets the router’s IP address.
• IP Port Number — sets the router’s IP port number, if applicable.
B
A
C
K
N
A
V
A
D
J
ETHERNET SETUP
IP Address 192.168.0.241
NEXT
IP QUAD
23IP Port Number
TEST
COMM
