Input Specifications
The table below lists Encore VPx input specifications.
Table A-2. Encore VPx Input Specifications
Input Parameter Specification
Via “Source Link” Input Analog Video RGBHV / RGBS / RGsB computer video, YPbPr video (SD or
HD), S-video, or Composite video
SD and HDSDI
Video
Per SMPTE 259M-C (NTSC / PAL resolution) SMPTE 292M
(HDTV)
DVI Per DDWG 1.0
Input
Resolutions
• NTSC/PAL
• Computer Resolutions VGA (640 x 480) through
UXGA (1600 x 1200)
• HDTV Resolutions up to 1920 x 1080 (720p, 1080i,
1080p)
• 2048 x 1080p (Digital Cinema format)
• Plasma Display Resolutions
Native Resolution
Background Channels
(2 per M/E board)
Analog Inputs RGBHV computer video on DVI-I connector
DVI Input Per DDWG 1.0 on DVI-I connector
Input
Resolutions
• Computer Resolutions: SVGA (800 x 600) through
UXGA (1600 x 1200)
• HDTV Resolutions (720p, 1080p)
• 2048 x 1080p (Digital Cinema format)
• Plasma Display Resolutions
Downstream Key Input
(1 per Encore Video
Processor)
Analog Inputs RGBHV computer video on DVI-I connector
DVI Input Per DDWG 1.0 on DVI-I connector
Input
Resolutions
• Computer Resolutions: SVGA (800 x 600) through
UXGA (1600 x 1200)
• HDTV Resolutions (720p, 1080p)
• 2048 x 1080p (Digital Cinema format)
• Plasma Display Resolutions
