114 Encore Presentation System • User’s Guide • Rev 04
4. Controller Orientation
Controller Sections
`çåíêçääÉê=pÉÅíáçåë
This section provides detailed descriptions of each Controller section. Illustrations for both
Controller models are provided, and the differences in functionality are clearly noted.
The following topics are discussed:
• Touch Screen Section
• System Keypad
• Alphanumeric Keypad
• Joystick Section
• Machine Control Section
• Console Lighting
• Preset Section
• Destination Bus
• Source Selection Bus
• Layer Control Section
• Layer Functions Section
• Live Switch Section
• Transition Section
• Group Control Section
• Program Preset Section
• Layer/Aux Control Section
• Transition Functions Section
• User Key Section
