146 Encore Presentation System • User’s Guide • Rev 04
5. Menu Orientation
Conventions in this Chapter
`çåîÉåíáçåë=áå=íÜáë=`Ü~éíÉê
Please note the following important conventions used in this chapter:
Button labels on the Touch Screen are shown in bold uppercase letters between
braces.
S Press {BORDR} to …
The term Processor is used to represent both the “standard” Video Processor
(
VP) and VPx, unless otherwise noted.
däçÄ~ä=oìäÉë
The following global rules apply to all menus:
Brackets — parameters and values displayed between brackets (e.g., [525])
cannot be changed.
ID “All” — For widescreen destinations, when the value “All” is shown for the ID
parameter, it represents the lowest numbered ID in the destination, as configured
(typically, number 1).
Alphanumeric Keypad — On the Controller LC, the Alphanumeric Keypad can
be used globally for certain numeric functions. In Chapter 7, refer to the “
Using
the Alphanumeric Keypad” section on page 310 for detailed instructions.
PS/2 Keyboard — On both Controllers, a standard PS/2 style keyboards can be
used globally for numeric entry, and also for “naming” certain functions. In
Chapter 7, refer to the “
Using the PS/2 Keyboard” section on page 311 for
details.
Press {HOME} to return to the Home Menu.
Press {BACK} to return to the menu from which you accessed the current menu.
Note
The {HOME} and {BACK} buttons will not be explained again
in this chapter.
