368 Encore Presentation System • User’s Guide • Rev 04
^K==péÉÅáÑáÅ~íáçåë
Communications Specifications
`çããìåáÅ~íáçåë=péÉÅáÑáÅ~íáçåë=
The table below lists Encore Presentation System communications specifications.
Table A-5. Encore Communications Specifications
Parameter Detail Specification
RS-232 Video Processor DB-9 Female, DCE, 115k Baud
Controller (Console) DB-9 Female, DCE, 115k Baud
Controller (EXT COMM) DB-9 Female, DCE, 115k Baud
Ethernet
Video Processor RJ-45, 10/100 Mbps Autosense
Controllers RJ-45, 10/100 Mbps Autosense
Tally
Controllers DB-25 Male, Dry-Contact Relay Closures
Keyboard Port
Controllers PS/2 Connector
MultiMedia Card
Controllers System specification version 3.31 compliant.
