Encore Presentation System • User’s Guide • Rev 04 283
6. System Setup
AUX Destination Setup
fã~ÖÉmol=çê=mêÉmolJff=^ìñ=aÉëíáå~íáçå=pÉíìé
This section provides instructions for setting up ImagePRO Aux and PrePRO-II Aux
destinations. Once assigned, the associated button(s) on the Controller’s
Destination
Bus
will be active.
S Prerequisites — Ensure that you are familiar with the ways in which
ImagePRO and PresentationPRO-II systems can be physically configured as
Aux destinations. In Appendix D:
~ Refer to the “PresentationPRO-II Aux Configuration” section on
page 398 for PresentationPRO-II details.
~ Refer to the “ImagePRO Aux Configuration” section on page 399 for
ImagePRO details.
Use the following steps to set up an ImagePRO or PrePRO-II Aux destination:
1. Ensure that your ImagePRO and/or PresentationPRO-II systems are properly
connected to the system
Switch via Ethernet. If not, in Chapter 3, refer to the
“
Installation” section on page 64 for instructions.
2. Ensure that you have properly configured one (or more) router outputs as “Aux”
outputs. If not, refer to the “
Router Setup” section on page 270 for instructions.
Step
19 deals specifically with Aux output setup.
3. In the System Keypad, press SYSTEM to access the System Menu.
4. Press {DEST SETUP} to display the Destination Setup Menu.
5. On the Destination line, select the Aux destination that you want to define.
6. Scroll to the Type line and select ImagePRO Aux or PrePRO-II Aux.
7. Press {AUX SETUP} to display the Aux Setup Menu.
8. On the Source Mapping line, two choices are available:
~ Select Input Patch if you want to map Aux sources according to how
inputs are patched to buttons on the
Source Selection Bus. Note that
this is the typical choice.
~ Select Direct Map if you want the Source Selection bus to be a 1:1
mapping of your router inputs — for
this Aux destination only.
9. On the ID line, select the ID of the ImagePRO or PrePRO-II to which you want to
route Aux sources.
10. In the Analog section:
a. On the Analog Router Name line, select the router from which analog
sources will be routed to the ImagePRO (or PrePRO-II).
b. On the Analog Router Output line, select the specific router output that
you designated as an
Aux output.
c. On the ImagePRO Input (or PrePRO-II Input) line, select the
ImagePRO or PrePRO-II input to which the analog router output is
connected.
Note
On the Controller SC, up to 6 destinations can be assigned.
On the Controller LC, up to 32 destinations can be assigned.
