Encore Presentation System • User’s Guide • Rev 04 195
5. Menu Orientation
System Menu
To use this feature, perform the following steps:
a. Dial in the first output number from which you want to start.
b. Define the VP/SP ID and the VP/SP input to which you want to connect
this output.
c. Press {ADD PATCH}. From this point, pressing {PATCH NEXT} will
automatically perform the following actions:
• Increment to the next Output Number.
• Increment the VP/SP Input Layer or the VP/SP ID, if the last
VP/SP Input Layer has been defined.
• Add the patch.
S For example, if you start out with the following:
~ Router Output: 12
~ VP ID: 1
~ VP Layer: 3A
Pressing
{PATCH NEXT} will automatically add the following data:
~ Router Output: 13
~ VP ID:1
~ VP Layer:3B
Pressing
{PATCH NEXT} again will automatically add the following patch data:
~ Router Output: 14
~ VP ID:2
~ VP Layer:1A
In Chapter 6, refer to the “
Router Setup” section on page 270 for important information
about the system’s default Output Patch Table.
