List of Replaceable Parts
Service Centers
6
6-79
Table 6-24. A19 Digital Power Supply PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1 CAP,AL,470UF,+-20%,160V 816835 1
C2 CAP,AL,10UF,+-20%,160V,SOLV PROOF 817064 1
C3 CAP,AL,330UF,+-20%,100V,SOLV PROOF 816785 1
C4,C9 CAP,AL,10UF,+-20%,63V,SOLV PROOF 816843 2
C5,C11 CAP,CER,0.10UF,+-20%,50V,X7R 853650 2
C6 CAP,AL,10000UF,+-20%,25V 816819 1
C7 CAP,AL,6800UF,+-20%.25V 782466 1
C8 CAP,AL,2.2UF,+-20%,50V,SOLV PROOF 816868 1
C10 CAP,AL,22UF,+-20%,35V 817056 1
C12,C13 CAP,AL,22000UF,+-20%,16V 822379 2
C14,C16,C19-23 CAP,CER,0.22UF,+-20%,50V,X7R 853648 7
C15 CAP,AL,100UF,+-20%,16V,SOLV PROOF 816850 1
C17 CAP,POLYPR,0.047UF,+-10%,630V 500827 1
C18 CAP,POLYPR,0.047UF,+-10%,160V 446773 1
C24,C25 CAP,CER,0.022UF,+80-20%,500V,Z5U 740340 2
CR1-4,CR9-12 DIODE,SI,200 PIV,1.0 AMP 586644 8
CR8,CR16, CR21-
24,CR29-34
DIODE,SI,100 PIV,1 AMP 742874
742874
742874
12
CR13 * DIODE,SI,N-JFET,CURRENT REG,IF 852137 1
CR17-20 DIODE,SI,50 PIV,1.0 AMP 379412 4
CR25-28 DIODE,SI,150 PIV,5.0 AMP 523720 4
CR35 * DIODE,GER,BV=66V,IO=50MA 180505 1
F1 FUSE,8X8.5MM,0.315A,250V,SLOW,RADIAL 832337 1
F2 FUSE,8X8.5MM,0.125A,250V,SLOW,RADIAL 832261 1
F3,F4 FUSE,8X8.5MM,2A,250V,SLOW,RADIAL 806331 2
F5 FUSE,8X8.5MM,3.15A,250V,SLOW,RADIAL 832253 1
H2 SCREW,PH,P,LOCK,SS,4-40,.375 256164 1
H3,H4 HEAT DIS,CLIP,1.00,1.18,.50,TO-220 643353 2
H5 HEAT DIS,VERT FINS,TO-3 342675 1
H6,H7 RIVET,S-TUB,OVAL,AL,.087,.343 838458 2
H11 SCREW,PH,P,LOCK,SS,4-40,.437 403782 1
L1-6 CHOKE,6TURN 320911 6
L7 INDUCTOR, 33UH 813485 1
L8 TRANSFORMER, PULSE 660589 1
M1,M2 FOOT,RUBBER,ADHES,GRY,.44 DIA,.20 THK 1601870 2
MP8,MP27 NUT,HEX,STL,4-40 110635 2
MP9,MP10 NUT,EXT LOCK,STL,6-32,.344OD 152819 2
MP11,MP12 GROMMET,SLOT,RUBBER,.438,.062 853291 2
MP13,MP14 EJECTOR,PWB,NYLON 494724 2
MP15,MP26 HEAT DIS,VERT,1.00X1.375X0.50,TO-220 831099 2
MP16 HEAT,DIS,ACC,NYL,TO-3 851907 1
MP21 INSUL PT,POWER,SI,.750,.500 534453 1
MP24 INSUL PT,TO-3,SI,1.650,1.140 473165 1
MP25 INSUL PT,TRANSISTOR MOUNT,DAP,TO-5 152207 1
MP28,MP29 SCREW,PH,P,LOCK,STL,6-32,.250 152140 2
MP30,MP31 SPACER,SWAGE,.250 RND,BR,6-32,.125 435578 2
P41 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 1
Q1 * TRANSISTOR,SI,BV=200V,80W,TO-3 261347 1 1
Q2,Q6 * TRANSISTOR,SI,NPN,HI-VOLTAGE 370684 2
Q3,Q7-10 * TRANSISTOR,SI,300V,10W,TO-202 107646 5
Q4 * TRANSISTOR,SI,VCB=200V,1W,TO-3 276899 1
Q5 * TRANSISTOR,SI,BV=60V,65W,TO-220 386128 1
R1 RES,CF,5.1,+-5%,0.25W 441287 1
R2 RES,CF,2K,+-5%,0.25W 441469 1
