NEAX2400 IPX Feature Programming Manual
Page 962 NDA-24297, Issue 1
M-41 Multiple Call Forwarding - Busy Line - CCIS
Service Conditions (cont’d)
5. SERVICE DISPLAY - CCIS [S-53] is available at the terminating node. The type of forwarding to be
displayed is CF BUSY.
6. When a call is terminated to an ATTENDANT CONSOLE [A-3] by the MULTIPLE CALL
FORWARDING-BUSY LINE - CCIS [M-41], the call type is BUSY.
7. The system data (ASYD, SYS1, Index 486, bit 0-2) decides the maximum number of times for activating
a call forwarding service between nodes through CCIS. The number of times is selected in the range of 1
time to 7 times (ASYD, SYS1, Index 486, bit 0-2 = 0 means the enhanced feature is not available).
8. The number of times for activating this service between CCIS nodes is decided by system data
programmed at the node that has the station operating the first Call Forwarding service through CCIS link.
However, when the node that accommodates the station operating the service first has not been
programmed, the number of times is decided at the node that accommodates the destination of the first
Call Forwarding - CCIS service.
9. When Multiple Call Forwarding - CCIS is activated and the last intermediate party forwards (returns) the
call to the first calling party, the calling party may hear either ringback tone or busy tone.
The Calling party hears ringback tone when the forwarding destination number, assigned to the last
intermediate party (intermediate party 2 in the example below), and the calling party number sent from the
calling party are identical.
Call Originating Station
CF-B - CCIS
CCIS
Ringing
CF-B
CF-A
CF-B
E: 4020
822
820
S: 2000
A: 4211
B
D
C
LEGEND
• CF-A: Call Forwarding -All Calls
Calling Party (S) Called Party (E)
4211
Dialed Number
CF BUSY 8202000
Type of
Forwarding
Calling Station
Number
Busy
Busy
Busy
2nd C.F. (All
Calls/Busy)
1st C.F. (All Calls)
Node A Node B
Intermediate
Party 1
Calling Party
Ringback Tone
Intermediate
Party 2
Ringing
