NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1
Page 905
Data Hotline - CCIS D-86
D-86 Data Hotline - CCIS
General Description
This feature allows data stations to access Data Terminal Equipment (DTE) in a satellite office of a CCIS network,
by automatically dialing a SPEED CALLING-SYSTEM [S-3] number.
Operating Procedure
1. Manual CALL Origination via a Data Adapter:
a.) Press the D
term
DATA key
b.) The DATA lamp will flash and the calling D
term
will display the following:
2. Manual Call Origination via Keyboard Dialing:
a.) Enter DM CALL at the terminal
b.) The display of the terminal will indicate the following:
3. Activation of Data Terminal Ready (DTR) via a Data Adapter:
a.) Activate Equipment Ready (ER) or DTR from the data terminal equipment.
b.) The D
term
will display the following:
4. Activation of DTR via Keyboard Dialing:
a.) Activate ER or DTR from the Data Terminal Equipment.
Service Conditions
The following hardware supports this feature:
D
term
: PA-4DLCC issue 14A/PA-8DLCH
PA-4DLCE issue 1A/PA 16ELCD (when set in DLCH mode)
PA-4DLCF
Data Module: PA-4DTLA issue 7A
Modem Trunk: PA-4MDTA issue 2A PA-M28
Interactions
1. SPEED CALLING-SYSTEM [S-3] must first be provided.
2. FORCED ACCOUNT CODES [F-7] and AUTHORIZATION CODES [A-20] cannot be programmed for
use via SPEED CALLING-SYSTEM.
3. Pauses are programmable from the MAT, using the P of the keyboard. Pauses consume one digit of the 24
digits available. A pause lasts for 2.8 seconds.
DATA
(Time Display)
XXXX
CALLING
(Time Display)
CALLING
(Time Display)
