NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1
Page 863
Centralized Billing - CCIS C-55
Operating Procedure (cont’d)
2. Station C goes off-hook; Stations A and C are connected with each other in conversation.
3. Stations A and C go on-hook; SMDR information is sent out to the CENTRALIZED BILLING CENTER.
4. Station B dials Station C in Node C; Station B receives ringback tone and Station C is rung.
STN (c)
STN (a)
[Node A]
[Node B]
STN (b)
CCIS
CCIS
[Node C]
Centralized Billing Center
[Node A (Main Node)]
RS-232C
SMDR Message
STN (c)
STN (a)
[Node A] [Node B]
STN (b)CCIS
CCIS
[Node C]
RG
RBT
RBT
