NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1
Page 667
Station Hunting - Terminal S-9
Interactions (cont’d)
• When PH = 0: Station hunt starts by dialing the pilot station number (telephone number) only. The
feature is not provided when the PHTELN is dialed.
9. The lead station is the first station programmed in the ASHP command.
10. When Programmed on LDM:
a.) When activating this feature via FCCS, when CALL FORWARDING - ALL CALLS [C-5] is in
service at a pilot station, a call directed to the station is forwarded to the designated station.
b.) When activating this feature via FCCS, when an incoming call to a pilot station is forwarded by
CALL FORWARDING - BUSY LINE [C-2] and the forwarded party (also a member of another
hunting group) is also busy, the resultant hunt target can be designated from the forwarding side
group or the forwarded side group. This can be specified by the ASYD command. For further
information, refer to Programming.
c.) When activating this feature via FCCS, if the following occurs, a non-pilot station is skipped in
the hunting circulation process:
• When CALL FORWARDING - ALL CALLS [C-5] is set at the non-pilot station.
• When CALL FORWARDING - BUSY LINE [C-2] is set at the non-pilot station and the station
is actually in the busy state.
d.) When activating this feature via FCCS, CALL FORWARDING - DON’T ANSWER [C-3] will
respond to any call (both pilot and non-pilot stations). After a certain period of no answer, the call
is forwarded to the designated station.
e.) When activating this feature via FCCS, this feature is not available for a call in recall state by
CALL BACK [C-1] or CALL HOLD [C-6].
f.) When activating this feature via FCCS, a Hot Line station cannot be assigned as a member of the
hunting group.
Busy Station
Idle Station
Ringing Station
Phantom Station
Secretary
Available
Other Hunt Group
Pilot
Hunt
Hunt
Phantom
Ringing
Another call to Pilot
Call to Phantom, set call
back / Message
Reminder to Pilot
Call to Pilot
When PH=0 (Station Hunting does not
occur by the phantom number) is
selected in APHN.
