NEAX2400 IPX Feature Programming Manual
Page 728 NDA-24297, Issue 1
S-129 SMDR Output Expansion - ANI/CPN
S-129 SMDR Output Expansion - ANI/CPN
General Description
This feature expands SMDR information output, by which calling numbers from Central Office may be output to
the expanded area.
Operating Procedure
No manual operation is required.
Service Conditions
1. When the expanded area information is used, SMDR equipment must corresponds to the expanded output
format.
2. Users may assign 24 kinds of output information (maximum 240 bytes) combined as they like.
Information exceeding 240 bytes is not output from its head.
When current information + ANI information (A) + new information D + F + P:
Output information:
No output information:
3. Multi output and dual output are available. (If dual output is assigned, it is possible that the formats are
different at each port depending on system data [e.g. expanded output is available/not available]).
S
T
X
O!KH
/
I
/
J
CCIS
OFFICE
CODE
AUTH
CODE
AID ANI
NO.
DNEW
INFO.
D
FNEW
INFO.
F
PNEW
INFO.
P
ZE
T
X
240 bytes
Exceeding Info.
S
T
X
O!KH
/
I
/
J
CCIS
OFFICE
CODE
AUTH
CODE
AID ANI
NO.
DNEW
INFO.
D
FNEW
INFO.
F
ZE
T
X
NEW
INFO.
P
P
Exceeding information is not output.
