NEAX2400 IPX Feature Programming Manual
Page 530 NDA-24297, Issue 1
M-48 Multi Channel Recording - DAT
Service Conditions (cont’d)
8. When the system encounters a busy trunk in an attempt to make a dubbing of the message to the remaining
trunks, the trunk is retried after a 16 second interval. Each trunk is attempted a maximum of 16 times. If
the final attempt is rejected because of busy, no further dubbing attempts will be made.
9. Only the portion in which a message has been recorded is played back.
10. The dubbing time is calculated by the following equation: (Dubbing Time) = (Recording time + 2 sec) x
(Number of Trunk). Refer to the following table to obtain the approximate time for dubbing:
11. This feature is not available to access a 4-DAT trunk through FCCS link.
Programming
STEP 1: ANPD - Assign Number of Necessary Digits (NND) for the 1st digit of the access code of MULTI
CHANNEL RECORDING.
STEP 2: ASPA - Assign access codes for the following Service Code Appendix (SSCA).
SRV
SIDA
SSCA 66 (= MULTI CHANNEL RECORDING <REC>)
68 (= MULTI CHANNEL RECORDING <RPY>)
STEP 3: ASFC - For this feature, Service Feature Restriction data must be entered on a Service Feature Class
(SFC) basis.
SFI
87 (= MULTI CHANNEL RECORDING <REC>)
90 (= MULTI CHANNEL RECORDING <REPLAY>)
STEP 4: ARTD - Assign Route Class Data for an announcement trunk.
STEP 5: ATRK - Assign the announcement trunk data.
STEP 6: MBTK - Assign the Make Idle status to the announcement trunk.
DUBBING TIME
NUMBER OF TRUNK
110152063 1
6 seconds 8 80 120 160 504 8n
16 seconds 18 180 270 360 1134 18 x 1
30 seconds 32 320 480 640 2016 32 x 1
46 seconds 48 480 720 960 3024 48 x 1
60 seconds 62 620 930 1240 3906 62 x 1
EXECUTION
OF DUBBING
16
sec
16
sec
16
sec
(BUSY) (BUSY) (BUSY) (BUSY) (BUSY)
RETRY #1 RETRY #2 RETRY #16
TIME
