NEAX2400 IPX Feature Programming Manual
Page 752 NDA-24297, Issue 1
T-7 Toll Restriction - 3/6-Digit
Programming (cont’d)
DAY/NIGHT:D (Day)
OGRT: 1 RSC: 3
DC: 92 TDI: 1(Connection is Allowed)
Repeat these same assignments for Digit Codes “93” through “99” to allow all local office codes.
To allow Area Codes 718, 212, and 201, repeat the ATDP command for the following Digit Codes:
DC: 91718 TDI: 1 (Connection is Allowed)
DC: 91212 TDI: 1 (Connection is Allowed)
DC: 91201 TDI: 1 (Connection is Allowed)
To allow office codes 239, 465, and 798 within Area Code 914, assign the ATDP command as follows:
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D (Day)
OGRT: 1 RSC: 3
DC: 91914 TDI: 2 (Go to AARP Command)
NND: 6 (Begin restriction after 91914, i.e; the 6th digit dialed.)
AARP Command-
OGRT: 1 RSC: 3
FLAG: 1 DC: 239 RES: 1 (Connection is Allowed)
Repeat these same assignments for the following Digit Codes:
OGRT: 1 RSC: 3 FLAG: 1 DC: 465 RES: 1
OGRT: 1 RSC: 3 FLAG: 1 DC: 798 RES: 1
This allows office codes 239, 465, and 798 within Area Code 914. All other office codes are
automatically restricted.
Note: This method of assignment allows office codes 239, 465, and 798 to any Area Code that is assigned as TDI
= 2 in ATDP. For example, if the assignment for Area Code 718 was changed from TDI = 1 (allowed) to
TDI = 2, then the office codes 239, 465, & 798 would also be allowed for Area Code 718.
If different Office Codes are to be allowed in the 718 Area Code (for example 623 and 567), then the
assignments for Area Codes 914 and 718 must be made as follows:
ATDP Command-
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D (Day)
RSC: 3 OGRT: 1
DC: 919 TDI: 2 (Go to AARP Command)
NND: 3
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D (Day)
RSC: 3 OGRT: 1
DC: 917 TDI: 2 (Go to AARP Command)
NND: 3
This tells the system to check AARP tables for restrictions for all Area Codes beginning with 9 and 7.
AARP Command-
OGRT: 1 RSC: 3 FLAG: 2
DC: 914239 RES: 1 (Connection is Allowed)
DC: 914465 RES: 1 (Connection is Allowed)
