NEAX2400 IPX Feature Programming Manual
Page 848 NDA-24297, Issue 1
C-48 Call Forwarding - Intercept - CCIS
Programming (cont’d)
STEP 3: MBTK - Assign the Make Idle status to the Announcement Trunk.
Note: If supervision is required, use the first two circuits of the COT card. Move the switch on the COT card to
PGT.
STEP 4: ARRC - If TIE Line or REMOTE ACCESS TO PBX [R-2] connection to the Announcement Service
Trunk is required, allow trunk-to-trunk connection using ARI-D-RES, Direct Connection.
STEP 5: AAED - Used to assign Announcement equipment.
DEAD LEVEL
Assign:
TN: Tenant Number;
EQP: (Announcement Equipment Number) = 0 (Dead Level). Example: If level 6 is not assigned,
an announcement is heard instead of reorder tone.
RT, TK: Route & Trunk number of the trunk connected to the announcement equipment:
C: Duration of Connection, 0/1: Disconnection occurs in 30 seconds / the connection is held
until the station releases. See the requirements of the announcement equipment.
R: Sending RBT, 0/1: Sending RBT/Not sending RBT. Normally assign data “0”.
A: Answer Signal Sending, 0/1: No answer from Incoming trunk/Answer from Incoming trunk.
Normally assign data “0”. No answer signal is sent to the CO. Therefore calling party will
not be billed for the call.
M: Multiple Connection 0/1: Single Connection/Multiple Connection. See the requirements of
the announcement equipment.
UNUSED NUMBER
Assign:
TN: Tenant Number;
EQP: (Announcement Equipment Number) = 1 (Unused Number).
Example: If ext.-7836 is not in the system, the announcement is heard instead of reorder
tone.
RT, TK: Route & Trunk number of the trunk connected to the announcement equipment:
C: Duration of Connection, 0/1: Disconnection occurs in 30 seconds/the connection is held
until the station releases. See the requirements of the announcement equipment.
R: Sending RBT, 0/1: Sending RBT/Not sending RBT. Normally assign data “0”.
A: Answer Signal Sending, 0/1: No answer from Incoming trunk/Answer from Incoming trunk.
Normally assign data “0”. No answer signal is sent to the CO. Therefore calling party will
not be billed for the call.
M: Multiple Connection 0/1: Single Connection/Multiple Connection. See the requirements of
the announcement equipment.
STEP 6: ACFR - Assignment of Call Forwarding Restriction. Upon determining which types of Call Class
Indexes (CCI) will be answered via CALL FORWARDING-INTERCEPT - CCIS (i.e., CCSA and
DID calls), allow those CCIs a Transfer Service Feature Index of 1, Call Forward-All Calls, Don’t
Answer, Busy.
COT Card
CKT 0
CKT 1
Ring, not used
Voice Tip
Voice
Supervisory Ground
