NEAX2400 IPX Feature Programming Manual
Page 98 NDA-24297, Issue 1
B-12 Brokerage Hotline - Outside
Service Conditions (cont’d)
15. The station, the Attendant Console / Desk Console (operator call), and the trunk can be a destination for
Hotline.
16. When Call Forwarding - All Calls/Busy Line/Don’t Answer service has been set to the called station, these
features are available for the call to the station.
17. When a calling party encounters a busy station, the call may bridge into the connection, depending on the
data assigned by the ASYD command.
Programming
STEP 1: ASDT - Assign to a 16LC circuit the following data:
TN: Tenant Number
STN: Station Number
LENS: Line Equipment Number (6 digits)
TEC: Telephone Class (1 - 31)
1: DP (10 pps)
2: PB
3: DP/PB
12: D
term
13: Data terminal via D
term
14: Hotline
15: CAS Line
18: Virtual circuit
Note
RSC: Route Restriction Class (0 - 15)
SFC: Service Feature Class (0 - 15)
STEP 2: ASPD - Assign ADC code, maximum of 3 digits; assign CD = telephone number, maximum 24 digits,
corresponding to the ADC.
STEP 3: AHLS - Assign the station number programmed above for the following parameters:
HOT TN: Hotline Tenant
STN: Hotline Station
TYPE: Connection Type 2 - Abbreviated Digit Code (ADC)
Connection Type 3 - Trunk Line
ADC: Abbreviated Digit Code (C) of the Destination Station
CON TN: Connecting Station’sTenant
CON STN: Connecting Station’sNumber
CON RT: Connecting Station’sRouteNumber
CON TK: Connecting Station’s Trunk Number
STEP 4: AKYD -AssigntoaD
term
a line appearance of the Hotline station number.
TN: Tenant Number
STN: Station Number
TP: Type of D
term
[0/1]:
KYN: Key Number (1 - 40)
KYI: Service Index
0: Key not used
1: Feature Key
