NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1
Page 753
Toll Restriction - 3/6-Digit T-7
Programming (cont’d)
DC: 914798 RES: 1 (Connection is Allowed)
OGRT: 1 RSC: 3 FLAG: 2
DC: 718623 RES: 1 (Connection is Allowed)
DC: 718567 RES: 1 (Connection is Allowed)
This allows just these office codes within these particular Area Codes. All other area codes beginning
with “7” or “9” are also restricted. At this point, if allowing Area code 714 is desired, assign AARP as
follows:
AARP Command-
OGRT: 1 RSC: 3 FLAG: 1
DC: 714 RES: 1 (Connection is Allowed)
Example 4 - RSC 4 Assignment
(Allow local plus all Area Codes except 808, 213, 408, and 714)
ATDP Command-
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D (Day)
OGRT: 1 RSC: 4
DC: 92 TDI: 1 (Connection is Allowed)
Repeat these same assignments for Digit Codes “93” through “99” to allow all local office codes.
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D (Day)
OGRT: 1 RSC: 4
DC: 912 TDI: 2 (Go to AARP Command)
NND: 3
DC: 913 TDI: 2 (Go to AARP Command)
DC: 914 TDI: 2 (Go to AARP Command)
\\\ (Through)
DC: 919 TDI: 2 (Go to AARP Command)
This tells the system to check AARP tables for all restrictions for Area Codes.
AARP Command-
OGRT: 1 RSC: 4 FLAG: 1 DC: 808 RES: 0*
OGRT: 1 RSC: 4 FLAG: 1 DC: 213 RES: 0*
OGRT: 1 RSC: 4 FLAG: 1 DC: 408 RES: 0*
OGRT: 1 RSC: 4 FLAG: 1 DC: 714 RES: 0*
OGRT: 1 RSC: 4 FLAG: 2 DC: 000000 RES: 1**
*This assignment restricts the Area Codes listed.
**DC: 000000” indicates all other Destination Codes except those already assigned Destination
Codes.
RES: Restriction Data: (0/1)
0: Not assigned Area Codes are restricted
1: Not assigned Area Codes are allowed.
The above assignment allows all other dialing patterns (Area Codes) except 808, 213, 408 and 714.
Example 5 - RSC 5 Assignment
(Allow local plus all Area Codes, but restricted from office code 976 within each Area Code)
