NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1
Page 801
Asynchronous Data Switching - CCIS A-44
Programming (cont’d)
16: Data Terminal Via Data Module
18: Virtual Circuit
19: TMM
20: PSM
23: ISDN Terminal
27: Eight Conference Equipment
RSC: Route Restriction Class (0-15)
For assignment of RSC, ARSC command
SFC: Service Feature Class (0-15)
For assignment of SFC, ASFC command
STEP 2: AKYD - Despite the fact that a station number is assigned in ASDT for the data number, only the voice
station number must be assigned to the D
term
. Assign the DATA and DTX key. The AUTO key is an
optional assignment. Assign as follows:
TN: 1
STN: Station Number
TP: Type of D
term
0/1:
RING:
0: No Ringing
1: Ringing All Lines
2: Ringing on Prime Line Only
3: Flexible Ring Assignment, enables RG parameter
KYN:Key Number (1 - 40)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line Key
KD: Assign as 0
FKY: Feature Key Number
RG: Ringing Assignment per Multi-line Appearance
0: No Ringing
1: Ringing in Day Mode Only
2: Ringing in Night Mode Only
3: Ringing Day and Night
The feature keys, DATA TRANSFER DTX (FKY = 31), DATA (FKY = 29) must be assigned.
DISPLAY/AUTO (FKY = 30) is optional.
STEP 3: ASFC - For TEC = 13 stations, assign an SFC that at a minimum SFI 11 = 0, DATA LINE
SECURITY.
STEP 4: ARSC - Construct a Route Restriction Class that allows access to the desired incoming and outgoing
routes.
STEP 5: ATNR - Allow tenant-to-tenant connection for Inter and Intra-tenant connections. Assign Tenant
Restriction Index (TRI) = 1.
STEP 6: ACFR - Allow all incoming Call Class Index (CCI) for Transfer Service Feature Index (TSFI)=1.
