NEAX2400 IPX Feature Programming Manual
Page 366 NDA-24297, Issue 1
F-31 Follow Phone
Service Conditions (cont’d)
12. When this service is activated, the key information of D
term
, which has the target station as a multi-line
will be changed automatically. For example:
13. If the multi-line LED of D
term
is lit (busy) when the station swaps, the line LED key may not light
immediately after the service is activated. The LED light normally after the user goes on-hook.
14. For the stations that belong to the following service groups, this service is available only for those stations
belonging to the same group.
CALL PICKUP [C-7, 30]
CALL PARK [C-29]
STATION HUNTING - CIRCULAR [S-7]
STATION HUNTING - TERMINAL [S-9]
UCD [U-1]
Note: In case of STATION HUNTING - SECRETARIAL [S-8], the function as the secretarial station does not swap
even when the station swaps. (The secretary station is not considered as a member of the hunt group.)
15. When following station activates this service, its destination station is not swapped.
a.) Station where following services are set:
• CALL FORWARDING - BUSY LINE set by the system
• CALL FORWARDING - DON'T ANSWER set by the system
• CALL FORWARDING - INTERCEPT/ANNOUNCEMENT [C-25]
b.) Predetermined station for HOTLINE [H-1]
c.) Predetermined station for OFF-HOOK ALARM [O-6]
d.) DIRECT-IN TERMINATION (DIT) [D-7] station
16. If D
term
has individual terminal data assigned, this service is available for D
term
s with identical terminal
data.
17. This service is not available for:
a.) D
term
with OAI service key.
b.) ACD agent console and supervisory console.
c.) D
term
with CALL WAITING LAMP - UCD [C-76].
18. This feature cannot be activated between D
term
s of different types. When different D
term
s are used, there
may be cases where the incoming call cannot be answered or some services cannot be activated, due to
lack of line/feature keys. In this case, the data can be restored by activating the service again or by
exchanging the terminal sets.
19. When activating this service, the terminals cannot be exchanged. (There may be some inconvenience if
number of Speed Calling keys, etc. differ between the terminals.)
Station A Station B Station C
Station A Station B Station C
-My Line 200
-My Line 200
-My Line 202
-My Line 203
-My Line 203
-My Line 200
-My Line 202
-My Line 203
-My Line 203
-My Line 202
