NEAX2400 IPX Feature Programming Manual
Page 536 NDA-24297, Issue 1
M-101 MF ANI to SMDR
M-101 MF ANI to SMDR
General Description
This feature allows an office receiving ANI information by means of MF signal to output the information to the
expanded SMDR area.
Operating Procedure
No manual operation is required.
Service Conditions
1. Output conditions are same as current conditions of MF ANI. (i.e., charging information for incoming
calls is output only).
2. About the expanded output format, refer to SMDR OUTPUT EXPANSION-ANI/CPN [S-129].
3. When the tandem connection is established through CCIS, the maximum digits of ANI information output
to the SMDR port are 16.
Programming
Also see TRUNK LINE APPEARANCE [T-23] for information on how to accommodate C.O. line on
aD
term
line/feature key.
STEP 1: ASYD - System Data 1, Index 241, Bit 4. 0/1 = No ANI output to SMDR/ANI output to SMDR.
System Data 1, Index 241, Bit 6. 0/1 = When the length of Caller ID exceeds the limit, only the former/
latter part of data appears on the LCD.
System Data 1, Index 390, Bit 0. Caller ID display pattern on the LCD. 0/1 = Calling Number/Calling
Name has priority.
System Data 1, Index 390, Bit 2. when using D
term
2-line LCD, the lower LCD can be used for
displaying Caller ID. 0/1 = Out/In service.
When Calling Number is output to SMDR, the following expanded format is used.
H = Origination
I = Termination
J = Station-to-Station
S
T
X
OKH
/
I
/
J
! OFFICE CODE OF
CALLED PARTY
(FOR CCIS)
AUTH
CODE
Identifier:
0 = Output is not available
1 = Displayed
2 = Display denied
3 = Service is not available
4 = Origination from public pay phone
Note:
For 0, 2 and 3, the ANI number is not output.
AANI
NO.
ZE
T
X
A = ANI Information
Z = End of SMDR
Information
1 96 104 129 130 131 1622
