NEAX2400 IPX Feature Programming Manual
Page 702 NDA-24297, Issue 1
S-25D Service Display - D
term
S-25D Service Display - D
term
General Description
This feature generates LCD displays corresponding to the various features as they are initiated.
Operating Procedure
Each display is automatically generated when a feature is initiated.
Service Conditions
1. Each display is controlled by system data and is produced accordingly. The service display may be
allowed or denied in system data on a per-system basis.
2. The contrast on the LCD Display Panel is controlled by two buttons on the top front of the D
term
.Press
the right (UP) button for a darker image or the left (DOWN) button for a lighter image.
3. The LCD will display one of the features being used.
TRANSFER - CALL TRANSFER [C-11]
PICKUP - CALL PICKUP [C-7]
CALL FORWARDING ALL - CALL FORWARDING - ALL CALLS [C-5]
CALL FORWARDING BUSY - CALL FORWARDING - BUSY LINE [C-2]
CALL FORWARDING NANS - CALL FORWARDING- DON’T ANSWER [C-3]
HUNTING - STATION HUNTING [S-7,8,9]
UCD UNIFORM CALL DISTRIBUTION [U-1]
4. For a transferred call, the LCD displays:
Note: When the telephone number of the transferring/transferred station exceeds 8 digits, the last 8 digits are
displayed. However, a maximum of a 16-digit transferred telephone number can be displayed on the middle
line of the LCD, depending on system data.
Programming
ASYD - System Data 1, Index 78, Bit 1. Is SERVICE DISPLAY in service? 0/1: No/Yes.
FCCS Programming
No unique programming is required for the FCCS network.
TRANSFER XXXX XXXX
(Time Display)
Transferring
Station
Transferred
Station
