NEAX2400 IPX Feature Programming Manual
Page 116 NDA-24297, Issue 1
C-2D Call Forwarding - Busy Line - D
term
Service Conditions (cont’d)
3. This feature is assigned to stations through CLASS OF SERVICE - INDIVIDUAL [C-15] programming
in system data.
4. There is no limitation to the number of stations that can set CALL FORWARDING - BUSY LINE [C-2]
simultaneously.
5. CALL FORWARDING - BUSY LINE - D
term
may also be accessed via the dial pad or SPEED CALLING
- ONE TOUCH [S-22].
Note: If this feature is accessed via the dial pad, it must be cancelled via the dial pad.
6. If separate access codes are programmed into system data for CALL FORWARDING - DON'T ANSWER
[C-3] and CALL FORWARDING - BUSY LINE [C-2], separate feature keys must be programmed on
each D
term
to equip it with both features.
7. CALL FORWARDING - BUSY LINE - D
term
can be provided on a tenant and/or an individual station
basis.
8. Call Forwarding on a tenant basis allows any incoming calls, which encounter a busy condition, to be
forwarded to a predetermined station or the ATTENDANT CONSOLE [A-3].
9. Individual CALL FORWARDING - BUSY LINE - D
term
supersedes tenant basis CALL
FORWARDING.
10. The display of an intermediate station on a D
term
's LCD panel may be allowed or denied according to
system data. This assignment is done on a system basis. The LCD displays:
Intermediate Station Calling/Called Party
Note: When the telephone number of the intermediate or calling/called station exceeds 8 digits, the last 8 digits
are displayed. However, a maximum of 16 digits calling/called telephone number can be displayed on the
middle line of LCD depending on the system data.
11. CALL FORWARDING - BUSY LINE - D
term
supersedes STATION HUNTING [S-7, 8, 9].
12. The operator answering a forwarded call can identify the called number on the ATTENDANT CONSOLE
[A-3] display.
13. If the called station is the pilot of a UCD [U-1] group and activates CALL FORWARDING - BUSY LINE
-D
term
, the calling station will queue to the UCD [U-1] group and will not CALL FORWARD.
14. If a calling station, ATTENDANT CONSOLE [A-3], or trunk receives busy tone after setting CALL
FORWARDING - BUSY LINE [C-2] and activates EXECUTIVE RIGHT-OF-WAY [E-1], CALL
WAITING - ORIGINATING [C-31], CALL WAITING - TERMINATING [C-12], or BUSY
VERIFICATION [B-3], these services will be activated to the calling station.
15. If all the stations in the terminating Station Hunt Group are busy, the forwarding call will hear busy tone
and will not return to the calling party's Hunting Group.
16. When MULTIPLE CALL FORWARDING - BUSY LINE [M-24] service is activated, hunting will be
performed at the last destination of the forwarded call, even though the multiple jumped stations are in a
Hunt Group.
17. When the pilot station of a Hunt Group activates CALL FORWARDING - BUSY LINE - D
term
to a station
(not a member of a Hunt Group) and system parameters specify that Call Hunting will be activated at the
forwarded station, the NEAX2400 IPX will send busy tone if the forwarded station is busy. If the system
parameters specify hunting at the forwarding station and the forwarded station is busy, the call will hunt
in the forwarding station's Hunt Group.
CF BUSY XXXX
XXXX
(Time Display)
