NEAX2400 IPX Feature Programming Manual
Page 246 NDA-24297, Issue 1
C-150 Call Block
Operating Procedure (cont’d)
To set the Restriction Number by dialing an optional number
1. Lift the handset.
2. Press the CALL BLOCK key.
3. Receive special dial tone.
4. Dial number to be restricted.
5. Receive service set tone after the preassigned inter-digit timer (default is 6 seconds).
Note 1
6. The CALL BLOCK key lights red.
7. The dialed number is registered as the Restriction Number.
To confirm the registered Restriction Number
1. Press the CALL BLOCK key when the station is idle (when the latest received calling number has been
registered, the number is displayed on the LCD).
2. Continue pressing the CALL BLOCK key in the same manner to confirm the other Restriction Numbers.
The other Restriction Numbers are displayed in consecutive order.
3. The registered Restriction Number is displayed for 5 seconds.
When using the MAT command to confirm the registered Restriction Number
1. Start the DCBD command.
2. Enter the telephone number or LENS.
3. Select to display the registered Restriction Number.
4. The Restriction Number, which is registered to the line corresponding to the specified telephone number
or LENS, is displayed.
To cancel the registered Restriction Number
1. Confirm that the Restriction Number to be cancelled is displayed on the LCD (See the above-mentioned
procedure “To confirm the registered Restriction Number”).
2. Press the “*” or “#” key for the Restriction Number to be cleared (depends on the system data), while the
corresponding number is displayed.
3. When all the Restriction Numbers are deleted, the LED of CALL BLOCK feature key (or soft key) goes
off.
Note 1: When the Restriction Number has already registered up to the maximum number, reorder tone is heard.
First cancel the former registered Restriction Number, then set the new Restriction Number again from the
beginning.
Note 2: When a D
term
Series E is used at the station, the LCD displays are as shown on the next page.
LCD displays for Service Set, Confirmation, and Cancel are shown on the following page. Set/Cancel can
be selected as the “*” or “#” key, depending on system data. Assignment of one of these keys as Cancel
key, will assign the other as the Set key.
24 digit display of D
term
Series E
• When the last incoming call is displayed:
L:XXXXXXXXXXXXXX
BLOCK ENTRY [*]
The first 14 digits of the latest calling number is
displayed on the right side of the LCD
The latest incoming call
