NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1
Page 915
E911 - ANI Unified Number of Digits - CCIS E-20
E-20 E911 - ANI Unified Number of Digits - CCIS
General Description
This feature allows a station or Attendant Console, called via CCIS, to perform E911-ANI service. This feature is
functionally identical to AUTOMATIC NUMBER IDENTIFICATION (ANI) [A-87].
Operating Procedure
The operating procedure is the same as that of a normal outgoing connection.
Service Conditions
1. This feature is available in the U.S.A. and Canada.
2. The ANI function for E911 outgoing connections is applied to:
a.) Least-Cost Route (LCR) call from a station by MF signalling.
b.) LCR call from an Attendant by MF signalling.
c.) LCR call by MF signalling from a station or Attendant Console called via CCIS.
3. ANI sending number by E911-ANI - CCIS is NXX-XXXX, which is the same as that by the previous
E911-ANI service.
4. Method of obtaining ANI sending number (example):
Caller’s station number: 12345 (closed numbering)
ANI assigned data:
RT: XX
AT: 0 (0 = STA/ATT)
(1 = not assigned special ATT number)
CC: 1 (0 = Main Central)
(1 = Satellite Central)
COC: 826 (Remote Office Code)
Skip: 4 (Number of digits to be skipped from the top of the STN)
Add: 3 (Number of digits to be added to ANI information)
DC: 789 (ANI information)
a.) Number of skip digits deleted from STN:
8261
2345
b.) The number created by combining the ANI information and the above number becomes the ANI
sending number:
7892345
c.) Sending ANI information:
KP-0-789-2345-ST
5. Sending digit patterns in E911-ANI - CCIS:
a.) Outgoing call from station/Attendant Console of the Main office.
• If OG call is from a station and ANI data is assigned:
KP-0
-N**-****-ST
• If OG call is from a station and ANI data is unassigned:
KP-2
-ST
ANI sending number
Information digit
Information digit
